B82793C0513N201 Common Mode Choke Suitable for reflow soldering

Ask Lasest Price
Brand Name :	Shareway
Model Number :	B82793C0513N201
Certification :	CE UL RoHS ISO9001:2008
Price :	Supportive
Payment Terms :	TT,Paypal
Supply Ability :	5000K.PCS/Month
Delivery Time :	Stock or 3 weeks

Add to Cart

Product Details
Company Profile

B82793C0513N201 Common Mode Choke Suitable for reflow soldering

B82793C0513N201 Common Mode Choke Suitable for reflow soldering

Construction

Current-compensated double choke
Ferrite core
LCP case (UL 94 V-0), silicone potting
Bifilar winding (B82793C0/K0)
Sector winding (B82793S0/L0)

Features

High rated currents, reduced components height
Qualified to AEC-Q200 (L ≤ 4.7 mH)
Suitable for reflow soldering
RoHS-compatible

Applications

Automotive applications, e.g. CAN bus
Industrial applications
Types with LR > 4.7 mH only for telecom applications

Terminals

Base material CuSn6
Layer composition Ni, Sn
Hot-dipped

Part NO.	LR mH	Lstray,typ nH	IR mA	Rtyp mΩ	Vtest V DC, 2 s
B82793C0502N201	0.005	40	1200	60	250
B82793K0602N201	0.006	30	2000	20	250
B82793L0602N201	0.006	250	2000	20	250
B82793C0113N201	0.011	50	800	80	250
B82793C0253N201	0.025	60	800	110	250
B82793S0253N201	0.025	1400	800	110	250
B82793C0513N201	0.051	70	800	140	250
B82793S0513N201	0.051	2300	800	140	250
B82793C0104N201	0.10	100	500	180	250
B82793C0474N215	0.47	100	700	170	750
B82793C0105N265	1.0	70	700	140	750
B82793C0225N265	2.2	120	500	400	750
B82793C0475N265	4.7	2500	400	550	750
For telecommunications
B82793C0206N265	20	300	100	1800	750
B82793C0476N265	47	1200	100	3700	750

Technical data and measuring conditions:

Rated voltage VR	42 V AC (50/60 Hz) / 80 V DC
Rated temperature TR	60 °C
Rated current IR	Referred to 50 Hz and rated temperature
Rated inductance LR	Measured with Agilent 4284A, 0.1 mA, 20 °C Measuring frequency: LR ≤ 1 mH = 100 kHz LR > 1 mH = 10 kHz Inductance is specified per winding.
Inductance tolerance	±30% (LR ≤ 0.47 mH), –30/+50% (LR ≥ 1 mH) at 20 °C
Inductance decrease ΔL/L	< 10% at DC magnetic bias with IR, 20 °C
Stray inductance Lstray,typ	Measured with Agilent 4284A, 5 mA, 20 °C, typical values Measuring frequency: LR ≤ 11 μH = 1 MHz LR > 11 μH = 100 kHz
DC resistance Rtyp	Measured at 20 °C, typical values, specified per winding
Solderability	SnPb: (215 ±3) °C, (3 ±0.3) s Sn96.5Ag3.0Cu0.5: (245 ±5) °C, (3 ±0.3) s Wetting of soldering area ≥ 95% (to IEC 60068-2-58)
Resistance to soldering heat	(260 ±5) °C, (10 ±1) s (to IEC 60068-2-58) Climatic category
Climatic category	40/125/56 (to IEC 60068-1)
Storage conditions (packaged)	–25 °C … +40 °C, ≤ 75% RH
Weight	Approx. 0.25 g

B82793C0513N201 Common Mode Choke Suitable for reflow soldering

Shape and Dimensions:

Product picture:

B82793C0513N201 Common Mode Choke Suitable for reflow soldering

HOW TO ORDER
1. Please send me your datasheet or part number you need.
2. We will offer the replacement quotation for your reference
3. The free samples are available for your approval.
4. After sample testing, we will step into the mass order.
5. The Proforma Invoice will send for your confirmation
6. After the goods finished, we send the goods to you and tell you the tracking number.
7. We will track your goods until you receive the goods.
Remarks:
1. Sample orders are avaliable.
2. Price is negotiable for orders of large quantity.
3. Customized orders (OEM/ODM orders) are avaliable.
4. Contact us for available flavors list. International Certifications:
1. ISO9001:2008
2. UL
3. Reach
4. RoHs
Our service:
1. 100% tested before shipping
2. Have alternative for Halo, Pluse, , We-online, Chilisin, Coilcraft......Same quality but better price
3. Free sample available
4. Provide new design for customer
